Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L

    Buy cheap Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L from wholesalers

    Buy cheap Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L from wholesalers
    • Buy cheap Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L from wholesalers

    Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L

    Ask Lasest Price
    Brand Name : Air Giant
    Model Number : DYMP80/20, DYMP140/20, DYMP80/30, DYMP140/30
    Certification : CAL,CMA,CNAS,ILAC-MRA,CCC
    Price : negotiation
    Payment Terms : L/C , D/P, T/T, Western Union, Paypal, Credit card
    Supply Ability : 300 sets per month
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    Enclosed Flooding Ig55 Inert Fire Gas Suppression System 80L 140L

    Inert Gas Argonite IG55 Fire Extinguishing System without residue for museum


    Description


    IG-55 is a clean agent fire extinguishing system using an inert gas (IG-55) consisting of 50% Nitrogen and 50% Argon and is used in total flooding systems. It has become widely accepted as the best performing, cost effective, and environmentally friendly inert gas fire extinguishing agent, offering extended hold times and great flexibility in design. IG55 fire suppression system utilises a superior valve design to automatically regulate the pressure of the extinguishant at discharge, providing an ideal discharge pressure and maintaining a constant flow rate throughout the discharge.


    Parameters


    No.SpecificationIG55(50% nitrogen;50% argon)
    1Capacity80Ltr140ltr
    2Working Pressure20MPa30MPa20MPa30MPa
    3Device ModelQMH20/80QMH30/80QMH20/140QMH30/140
    4Filling Capacity of Gas22.32kg33.48kg42kg58.2kg
    5Outside Diameter of CylinderΦ279mmΦ267mmΦ406mmΦ356mm
    6Height of Cylinder1710mm1870mm1460mm1925mm
    7Filling Rate0.299kg/L0.415kg/L0.300kg/L0.201kg/L
    8Spraying Time≤120s
    9PowerDC24V/1.6A
    10Nitrogen Pressure of Driving Device6.0±1.0MPa(20℃)
    11Condition of Reserving Room for Containertemperature: 0~50℃

    System Composition


    • Storage cylinder group, storage cylinder group frame, nitrogen driving device, nitrogen driving device frame,


    the cylinder valve, liquid flow check valve, air flow check valve, electromagnetic starter, gas conveying pipeline, collecting pipe, choice valve, three links, reducer tee, reduceing elbow, flange, safety valve, pressure transmitter, pipe, nozzle, chemicals, fire detector, fire controller, sound and light alarm, alarm bell, gas light, emergency start / stop button, etc.


    Features and benefits


    • Suitable for occupied areas
    • Electrically non – conductive
    • Chemically inert
    • Colourless, odourless and flavourless
    • No residue to clean up after the discharge
    • Zero Ozone Depletion Potential (ODP)
    • No greenhouse effect
    • No global warming impact
    • No decomposition products
    • No fog and no loss of post-discharge visibility
    • Non corrosive/toxic
    • Stored as a gas
    • Suitable for occupied areas
    • Excellent post-discharge visibility
    • Very low refill cost.
    • Easy to obtain anywhere in the world

    Application


    • DATA Centres
    • Comms Rooms
    • Telecommunication facilities
    • UPS Rooms
    • Medical facilities

    Packages


    We always pack it with polyfoam first and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.
